Name: Street Range

Display Field: STREET_NAME_COMPLETE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;font-size:12pt"><P><SPAN>Line geometry with attributes displaying street range segments in East Baton Rouge Parish, Louisiana.</SPAN></P><P><SPAN /></P><P><A href="http://city.brla.gov/gis/metadata/STREET_RANGE.html" STYLE="text-decoration:underline;"><SPAN>Metadata</SPAN></A></P></DIV>

Copyright Text: EBRGIS; Department of Information Services

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 500000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.2479070549488726E8
YMin: -9.125508333922587E7
XMax: 1.3135237216155392E8
YMax: 3.682155960732515E7
Spatial Reference: 102682  (3452)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: ROAD_TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: INTERSTATE
  Label: Interstate
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 3
• Value: US ROUTE
  Label: US Route
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [250, 52, 17, 255]
  Width: 3
• Value: STATE ROUTE
  Label: State Highway
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 112, 255, 255]
  Width: 2
• Value: ARTERIAL
  Label: Arterial Street
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 0
• Value: LOCAL
  Label: Local Street
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 0
• Value:
  Label: Private Drive
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• ID ( type: esriFieldTypeOID, alias: ID )
• LRS_ID ( type: esriFieldTypeInteger, alias: LRS ID )
• ST_SEGMENT_ID ( type: esriFieldTypeString, alias: Segment ID, length: 25 )
• ST_NAME_ID ( type: esriFieldTypeDouble, alias: Street Name ID )
• STREET_NAME_COMPLETE ( type: esriFieldTypeString, alias: Full Street Name, length: 132 )
• ST_PREFIX_DIR ( type: esriFieldTypeString, alias: Street Prefix Direction, length: 2 )
• ST_PREFIX_TYPE ( type: esriFieldTypeString, alias: Street Prefix Type, length: 50 )
• ST_NAME ( type: esriFieldTypeString, alias: Street Name, length: 50 )
• ST_SUFFIX_TYPE ( type: esriFieldTypeString, alias: Street Suffix Type, length: 20 )
• ST_SUFFIX_DIR ( type: esriFieldTypeString, alias: Street Suffix Direction, length: 2 )
• ST_EXT ( type: esriFieldTypeString, alias: Street Extension, length: 3 )
• NOTATION ( type: esriFieldTypeString, alias: Notation, length: 50 )
• SUBDIVISION ( type: esriFieldTypeString, alias: Subdivision, length: 75 )
• PRIVATE_STREET ( type: esriFieldTypeString, alias: Private Street, length: 3 )
• JURISDICTION ( type: esriFieldTypeString, alias: Jurisdiction, length: 50 )
• ST_SEGMENT_NUM ( type: esriFieldTypeDouble, alias: Street Segment No )
• FROM_ADD_LEFT ( type: esriFieldTypeInteger, alias: From Address Left )
• TO_ADD_LEFT ( type: esriFieldTypeInteger, alias: To Address Left )
• FROM_ADD_RIGHT ( type: esriFieldTypeInteger, alias: From Address Right )
• TO_ADD_RIGHT ( type: esriFieldTypeInteger, alias: To Address Right )
• ST_DIRECTIONAL ( type: esriFieldTypeString, alias: Street Direction, length: 1 )
• ONE_WAY ( type: esriFieldTypeString, alias: One Way, length: 2 )
• ONE_WAY_DIRECTION ( type: esriFieldTypeString, alias: One Way Direction, length: 1 )
• ST_ELEVATION_LEVEL ( type: esriFieldTypeDouble, alias: Street Elevation Level )
• FROM_ELEVATION_LEVEL ( type: esriFieldTypeDouble, alias: From Elevation Level )
• TO_ELEVATION_LEVEL ( type: esriFieldTypeDouble, alias: To Elevation Level )
• ST_BEGIN_MEAS_SF ( type: esriFieldTypeDouble, alias: LRS Begin Measurement (ft) )
• ST_END_MEAS_SF ( type: esriFieldTypeDouble, alias: LRS End Measurement (ft) )
• GEOM_REVERSED ( type: esriFieldTypeInteger, alias: Reversed Geometry )
• ST_OWNER ( type: esriFieldTypeString, alias: Street Owner, length: 32 )
• ST_TYPE ( type: esriFieldTypeString, alias: Street Type, length: 32 )
• ROAD_TYPE ( type: esriFieldTypeString, alias: Road Type, length: 20 )
• ROAD_CLASS ( type: esriFieldTypeString, alias: Road Class, length: 50 )
• CAD_FTC ( type: esriFieldTypeString, alias: Census FCC, length: 3 )
• PARITY_LEFT ( type: esriFieldTypeString, alias: Parity Left, length: 1 )
• PARITY_RIGHT ( type: esriFieldTypeString, alias: Parity Right, length: 1 )
• POSTAL_COMMUNITY_LEFT ( type: esriFieldTypeString, alias: Postal Community Left, length: 50 )
• POSTAL_COMMUNITY_RIGHT ( type: esriFieldTypeString, alias: Postal Community Right, length: 50 )
• ZIP_CODE_LEFT ( type: esriFieldTypeInteger, alias: ZIP Code Left )
• ZIP_CODE_RIGHT ( type: esriFieldTypeInteger, alias: ZIP Code Right )
• COMMUNITY_LEFT ( type: esriFieldTypeString, alias: City Left, length: 50 )
• COMMUNITY_RIGHT ( type: esriFieldTypeString, alias: City Right, length: 50 )
• PARISH_NAME_LEFT ( type: esriFieldTypeString, alias: Parish Left, length: 30 )
• PARISH_NAME_RIGHT ( type: esriFieldTypeString, alias: Parish Right, length: 30 )
• PARISH_FIPS_LEFT ( type: esriFieldTypeInteger, alias: FIPS Left )
• PARISH_FIPS_RIGHT ( type: esriFieldTypeInteger, alias: FIPS Right )
• STATE_LEFT ( type: esriFieldTypeString, alias: State Left, length: 2 )
• STATE_RIGHT ( type: esriFieldTypeString, alias: State Right, length: 2 )
• FEDERAL_ROUTE ( type: esriFieldTypeString, alias: Federal Route, length: 10 )
• FEDERAL_ROUTE_TYPE ( type: esriFieldTypeString, alias: Federal Route Type, length: 10 )
• ALT_FEDERAL_ROUTE ( type: esriFieldTypeString, alias: Alternate Federal Route, length: 10 )
• ALT_FEDERAL_ROUTE_TYPE ( type: esriFieldTypeString, alias: Alternate Federal Route Type, length: 10 )
• STATE_ROUTE ( type: esriFieldTypeString, alias: State Route, length: 10 )
• STATE_ROUTE_TYPE ( type: esriFieldTypeString, alias: State Route Type, length: 10 )
• ALT_STATE_ROUTE ( type: esriFieldTypeString, alias: Alternate State Route, length: 10 )
• ALT_STATE_ROUTE_TYPE ( type: esriFieldTypeString, alias: Alternate State Route Type, length: 10 )
• NUMBER_LANES ( type: esriFieldTypeSmallInteger, alias: Number of Lanes )
• CURB ( type: esriFieldTypeString, alias: Curb, length: 5 )
• SHOULDER ( type: esriFieldTypeString, alias: Shoulder, length: 5 )
• SPEED_MPH ( type: esriFieldTypeDouble, alias: Speed MPH )
• TRUCK_ROUTE ( type: esriFieldTypeString, alias: Truck Route, length: 3 )
• DRAINAGE_MAINT_RESPONSIBILITY ( type: esriFieldTypeString, alias: Drainage Maintenance Responsibility, length: 25 )
• EMERGENCY_FUNDING ( type: esriFieldTypeString, alias: Emergency Funding, length: 50 )
• PRIORITY_TO_KEEP_OPEN ( type: esriFieldTypeString, alias: Priority to Keep Open, length: 33 )
• RESTRICTED_ACCESS ( type: esriFieldTypeString, alias: Restricted Access, length: 3 )
• STREET_INCEPT_DATE ( type: esriFieldTypeDate, alias: Street Incept Date, length: 8 )
• STREET_END_DATE ( type: esriFieldTypeDate, alias: Street End Date, length: 8 )
• DATA_SOURCE ( type: esriFieldTypeString, alias: Data Source, length: 10 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• MODIFIED_DATE ( type: esriFieldTypeDate, alias: Last Edited Date, length: 8 )
• GEOMETRY ( type: esriFieldTypeGeometry, alias: GEOMETRY )

Supported Operations:   Query   Query Attachments   Generate Renderer   Return Updates
